   EC&M's CodeWatch
  Today's Headlines
 Vote for the 2011 Product of the Year and Qualify for a Chance to Win $100!
 Idaho Electrical Board Seeks Comments on Adoption of 2011 NEC
 What's Wrong Here?
 Code Q&A
 Code Quiz

Important Notice


Your vote will help us identify the 2011 Platinum, Gold, and Silver Product of the Year award winners. EC&M subscribers, simply review the products from the 2011 EC&M Product of the Year category winners list, and then choose your favorite from the drop-down menu. Three lucky voters will be randomly selected to receive $100.

The voting poll will remain open through 5 p.m. on May 20. Please, only one vote per EC&M subscriber. Any votes received from manufacturers, PR firms, or non-EC&M subscribers will not be counted.

Code News Update


As noted on the Idaho Division of Building Safety website, the Idaho Electrical Board is considering adoption of the 2011 edition of the National Electrical Code (NEC). A draft administrative rule outlines a number of amendments to the bonding requirements of permanently installed pools and elimination of the revision to the AFCI requirement in Article 210.12, which effectively expands AFCI protection beyond the bedrooms to most areas of a residence. It also notes an effective date of July 1, 2012.

Feel free to send your comments on the adoption of the 2011 NEC to al.caine@dbs.idaho.gov. All comments will be forwarded to the Idaho Electrical Board. The Electrical Board will review the draft rules and comments at its April 21st meeting.

Code Violations

What's Wrong Here?

By Joe Tedesco

Think you know how this installation violates the NEC?

Visit EC&M's website to see the answer.

Hint: Resurrected bodies

Code Quandaries

Code Q&A

By Mike Holt

Q. What is the rule for adjusting the ampacity of conductors based on the number of conductors in the raceway?

Visit EC&M's website to see the answer.

Code Challenge

Code Quiz

By Steven Owen

Per 250.190(C), when installing 5kV-rated, metallic insulation shielded, current-carrying conductors, is it permitted to use the metallic tape insulation shield and drain wire as an equipment grounding conductor for a solidly grounded system?
Note: The metallic insulation shield encircles the conductor.

  1. No. This is not permitted for a solidly grounded system.
  2. Yes, as long as the metallic shield is rated for the clearing time of the ground fault current protective device operation without damaging the metallic shield.
  3. Yes, as long as the minimum size of the phase conductors are 500kmcil or larger.
  4. Yes, as long as the equivalent area of the metallic shield is equal to or greater than 2 AWG copper.

Visit EC&M's website for the answer and explanation.
